BfS Angled Caps offer sprayer operators the opportunity of achieving the benefits of angling the spray forwards or backwards, whilst using their existing nozzles.

Angled Caps provide a 30° spray angle using all 8mm nozzles

- Improved vegetation coverage

- Increased chemical efficacy

- Enhanced disease control

The Dribble Bar II has a re-designed flow-control disc now with 11 settings giving extra application rate options, but retains the unique "dial-a-rate setting" flow rate adjustment.  It accurately applies liquid fertiliser through four equally-spaced openings along the Dribble Bar.

The AutoStreamer developed and manufactured by BfS works on sprayers with flow based rate controllers.  Accurate application of liquid fertiliser is made simple as the operator has only to enter the litres per hectare required, factor in the specific gravity (SG) and begin to apply.  Changing the application rate is equally simple and undertaken from within the cab.  The AutoStreamer is manufactured in chemical, glass reinforced plastic and is easily fitted to most boom sprayers.

5 Star is a single nozzle with variable application rates.  Designed to operate at 70cm above target.  5 streams provide excellent coverage.

Giving reduced risk of scorch damage.

Less drift, less waste.

Our 5 Star Plus nozzle for flow based controllers provides 368 litres/hectare of 30N at 2.5 bar pressure and 12 KPH 700mm boom operating height.

One nozzle covers the same output as 3 standard, non-variable, nozzle sizes.  Fits all standard nozzle bodies and any boom configuration.

BfS Nova Liquid Fertiliser applicator cap distributes liquid fertiliser from 5 streams, to evenly cover the 50cm distance between nozzle bodies.

Designed to be used either as a standalone nozzle, or in conjunction with the BfS Dribble Bar II, for those 'difficult to fit' positons where a Bar will not fit and a cap is required.

Available in ISO colours red, brown, grey and white with more sizes to be added to the range in the future.

BfS FlowCheck is a simple, low cost, but extremely effective piece of equipment that enables the operator to check the output of a sprayer nozzle accurately, without using a measuring cylinder and a stopwatch.

Each FlowCheck is individually calibrated at a pressure of 3bar, and its use enables the operator to accurately measure the flow rates from eight different nozzle sizes.

A unique calibration number appears on every unit supplied.

FlowCheck is accepted by NSTS for use in their tests.

Grab  Big Brute Agricultural Catalogue - full of the most popular Big Brutes and accessories for agricutural cleaning.

Precision moisture sensors and application equipment for all baler types

Specialising in the application of tungsten carbide, J.J.Metcalfe & Son Ltd focus on manufacturing wearing parts for agriculture that provide a consistently high performance throughout a long life using high grade steels, heat treatment methods and hard facing alongside tungsten carbide.

J.J.Metcalfe & Son’s extensive knowledge on the manufacture of castings and the application of tungsten carbide, means that they now supply some of the industry’s largest brand names.
